Canadian Blower Company



Tri-Lobe Positive Displacement Blowers, due to rotor tips disposed at 120º on each rotor, cause the rotor set to be much more resistant to angular deflection along it's length, than two lobed rotor sets, which have lobe tips disposed at 180º each - this extra "stiffness" provides less deflection at any load, thus minimizing possible rotor contact with both the cylinder and it's sister rotor during operation.

Positive Displacement Blowers (of the "Roots" type design)  are highly developed standard production machines designed and adapted to find use in a wide variety of applications:

Pneumatic conveying of bulk materials: In suction or discharge pressure. Machine sizes range from small blowers installed in tank vehicles to very large ones used in pneumatic elevators for vacuum operated ship unloaders. The hourly capacity of such unloading installations is up to 1000 tons at present.

Pressurized aeration of basins in sewage treatment plants: Filter flushing blowers in drinking water production plants. Gas boosting blowers rated for internal static pressures of up to 25 bar. High vacuum boosters are equipped with special shaft seals.

Conveying of pratical all gases: found in the chemical, petrochemical, and metallurgical industries. Special designs are available to handle aggressive gases. Machines used in both conventional and nuclear power plants comply with the various categories of safety regulations.
















































Fans with ambient air cooling systems handling hot airstreams must have sufficient airflow and be kept in operation until airstream temperatures cool below 120 F to prevent damage to the fan unit. The Tubeaxial fan ambient air cooling system is only effective while fan is operating.

Buffalo Fan Co. has introduced high temperature construction on its axial flow ventilators.  There are a few steps of fan heat construction available: 200 F, 725 F, 800 F. High temperature inline fans are ideal for industrial oven and dryer exhaust systems where pressure requirements are minimal and compact light-weight designs are advantageous.

200 F High Temperature Duct Fans come with special heat bearings and a belt drive with increased safety factor.

650 F Tubeaxial Fan design involves special belt tunnel cooling system that induces a flow of cooler, ambient air through the belt well and inner tube, cooling the fan's internal components. Depending on temperature requirements, modifications include high-temperature alloy fan wheel, special drive components, and modifications to provide internal ambient air cooling.

800 F Vaneaxial Fans are designed to operate continuously at temperatures to 800 deg. F, and include an auxiliary cooling fan that forces air through the bearing compartment and exits out through the insulated belt opening taking away excessive heat from the shaft and bearings. A high temperature shaft seal is also standard on this design.

Fans handling hot airstreams must have sufficient airflow and be kept in operation until airstream temperatures cool below 120 F to prevent damage to the fan unit. The Tubeaxial fan ambient air cooling system is only effective while fan is operating.

Buffalo Fan Co. complete high temperature fans line now include:

- Operating up to 2200 F, centrifugal, axial and plug fan types;
- Pre-engineered and custom made fans for all types of applications with vaiety of impeller types and accessories;
- Buffalo Fan engineers provide a professional advice and recommend a right fan for every application & oven / plenum design;
- The fan offering provides competitive replacement fans to Garden City, Lau, IGE, Alloy Fabricating fan models; repairs, re-build & balancing;
- Unique high temperature water-cooled motors for operation up to 2300 F;

in the two major types of high temperature fans - centrifugal and axial:

Centrifugal Wheels:

    * Multiblade forward curve wheel.  This type of wheel is usually specified where there is a necessity for large volumes of flow against low to medium static pressure requirements.  The forward curve blade is that it delivers the same volume of air as either the backward or radial blade wheel, at a lower fan speed, which is important due to wheel stresses at elevated temperatures.  This fan is the most common type used in all types of heat treatment operations except where a buildup of material on the blades could occur, as wheel unbalance would result.
    * Radial Blade, paddle wheel type fans.  This type of wheel is usually specified where there is a necessity for medium volumes of flow against medium to large static pressures. The paddle wheel is considered a self cleaning type of wheel.  It could be used where there are various materials or dust in the air stream.  Due to its structurally strong design, it is used in many heat treatment applications at very high temperatures where maximum fan longevity is desired.

Axial Blade Wheels:

    * The axial blade wheel is usually specified where there is a need for very large volumes of flows against low static pressure.   Axial wheel like the multi-blade forward curve type wheel could cause an axial fan to deliver different air volumes at the same static pressure, if the total pressure requirement of the fan system was underestimated. This type of fan is ideally suited where a large volume of flow is required with a minimum of duct work and is used extensively for small and large furnaces, such as aluminum annealing.
